| Turret
|
Superstructure
|
Hull
|
| Front
|
250mm@15°(259.0mm)
|
Front
|
150mm@50°(233.0mm)
|
Front
|
100mm@50°(156.0mm)
|
| Side
|
85mm@25°(94.0mm)
|
Side
|
80mm@0°(80.0mm)
|
Side
|
80mm@0°(
80.0mm)
|
| Rear
|
80mm@10°(81.0mm)
|
Rear
|
89mm@30°(103.0mm)
|
Rear
|
80mm@30°(92.0mm)
|
| Top
|
30mm@90°(30.0mm)
|
Top
|
30mm@90°(30.0mm)
|
Top
|
30mm@90°(30.0mm)
|
|
Mantlet
250 mm
|
|
Armour (x)mm @ (y)° (Effective mm @ 0°)
|
|
Effective Armour - Maximum 250
(mm) - Minimum 30
(mm) |
|
| Manufactured from - to |
Weight |
|
1944
- Unknown
|
|
70
(tonnes) |
| M.G's small |
Crew |
|
1
|
|
6
|
| M.G's Large |
Length |
|
-
|
|
7.46
(mtr) |
| Width |
Height |
| |
3.66
(mtr) |
|
2.85
(mtr) |
| Road Speed |
Cross Country Speed |
|
24
(mph) |
|
12
(mph) |
| Range Road |
Range Cross
Country |
|
-
(miles) |
|
-
(miles) |
| Fuel Type |
Fuel Capacity |
| |
Petrol
|
|
-
|
| Horse Power |
|
| |
-
|
|
|
|
Details currently unavailable
|
|
|
| |
| 12.8cm Pak 44 L/71
|
| | Calibre | 128 mm |
| | Muzzle Velocity | 920 m/sec |
| | Shell Weight | 28.3 Kg |
|
| Penetration (mm through vertical plate - calculated) |
| Range(metres) |
100 |
200 |
400 |
800 |
1200 |
1600 |
2000 |
2400 |
| Penetration(mm) |
216 |
214 |
210 |
203 |
195 |
188 |
180 |
173 |
| Flight Time(secs) |
0.1 |
0.22 |
0.44 |
0.91 |
1.39 |
1.9 |
2.42 |
2.97 |
|
|
|
|
  ©
