| Turret
|
Superstructure
|
Hull
|
| Front
|
30mm@15°(31.0mm)
|
Front
|
50mm@21°(54.0mm)
|
Front
|
50mm@21°(54.0mm)
|
| Side
|
30mm@25°(33.0mm)
|
Side
|
50mm@9°(51.0mm)
|
Side
|
50mm@9°(
51.0mm)
|
| Rear
|
30mm@12°(31.0mm)
|
Rear
|
53mm@0°(53.0mm)
|
Rear
|
53mm@0°(53.0mm)
|
| Top
|
30mm@90°(30.0mm)
|
Top
|
18mm@90°(18.0mm)
|
Top
|
18mm@90°(18.0mm)
|
|
|
|
Armour (x)mm @ (y)° (Effective mm @ 0°)
|
|
Effective Armour - Maximum 50
(mm) - Minimum 18
(mm) |
|
| Manufactured from - to |
Weight |
|
1941
- Unknown
|
|
22.3
(tonnes) |
| M.G's small |
Crew |
|
2
|
|
5
|
| M.G's Large |
Length |
|
-
|
|
5.64
(mtr) |
| Width |
Height |
| |
3.02
(mtr) |
|
2.56
(mtr) |
| Road Speed |
Cross Country Speed |
|
25
(mph) |
|
15
(mph) |
| Range Road |
Range Cross
Country |
|
-
(miles) |
|
-
(miles) |
| Fuel Type |
Fuel Capacity |
| |
Petrol
|
|
-
|
| Horse Power |
|
| |
-
|
|
|
|
Details currently unavailable
|
|
|
| |
| 5.0cm KwK 39 L/60 AP
|
| | Calibre | 50 mm |
| | Muzzle Velocity | 835 m/sec |
| | Shell Weight | 2.06 Kg |
|
| Penetration (mm through vertical plate - calculated) |
| Range(metres) |
100 |
200 |
400 |
800 |
1200 |
1600 |
2000 |
2400 |
| Penetration(mm) |
75 |
73 |
70 |
64 |
58 |
52 |
45 |
39 |
| Flight Time(secs) |
0.12 |
0.24 |
0.5 |
1.07 |
1.7 |
2.41 |
3.21 |
4.13 |
|
|
|
|
  ©
